🛠️ Agentic Infographic Workflow Postmortem

I recently built an agentic GitHub Actions workflow to generate a static PLG infographic from multiple public data sources and open a pull request with the output.

It worked eventually, but only after a sequence of failures that were useful to analyse. This post documents exactly how the workflow was created, what broke, and how each issue was resolved.

What the workflow was meant to do

The goal was simple:

1. Collect profile data from multiple sources.
2. Generate one static HTML infographic.
3. Upload it as a workflow artifact.
4. Open a pull request with the generated file.

The final output path is:

• static/infographic/index.html

Data sources used

The workflow pulls data from:

• Repository README in sujithq/sujithq.github.io
• GitHub profile README in sujithq/sujithq
• Microsoft Learn transcript JSON in sujithq/ms-learn
• GitHub API stats for sujithq
• Optional data from andrediasbr/github-certification-ranking

Cross-repo reads were enabled via tools.github.allowed-repos.

Initial workflow shape

The workflow was built with gh-aw front matter plus safe outputs:

• upload-artifact for exposing generated HTML
• create-pull-request for controlled write operations
• threat-detection to block unsafe active content

The HTML was intentionally constrained to be static:

• Inline CSS only
• No JavaScript
• No external assets
• No forms, iframes, or tracking

Failure timeline and resolutions

1) Compilation and lock-file churn

Symptom: Early iterations had compile and lock file consistency issues.

Root cause: Workflow markdown changes were not always followed by a fresh compile.

Resolution: Run gh aw compile .github/workflows/plg-infographic-github.md after each material change, then keep the lock file in sync.

2) Threat detection false positives

Symptom: Safe output checks flagged benign HTML/CSS output.

Root cause: Default detection was too generic for this static page use case.

Resolution: Customised safe-outputs.threat-detection.prompt to explicitly allow plain layout/styling and only flag active or risky web behaviour.

3) Transient platform instability

Symptom: Several runs failed with awf-api-proxy unhealthy.

Root cause: Infrastructure-level transient issue, not workflow logic.

Resolution: Rerun. No workflow code fix was required for this specific error.

4) Artifact upload path mismatch

Symptom: upload_artifact failed with no files matched.

Root cause: The agent generated the file as docs/infographic.html but called upload_artifact with infographic.html.

Resolution: Allowed both paths in safe-outputs.upload-artifact.allowed-paths and made the upload instruction explicit about valid paths.

5) Staging directory empty

Symptom: Safe outputs failed with: path does not exist in staging directory.

Root cause: Artifact upload expected a staged file, but the staging directory was empty at validation time.

Resolution: Set:

safe-outputs:
  upload-artifact:
    staged: false
    defaults:
      if-no-files: ignore

This avoids hard failure for missing staged files and reads from workspace path instead.

6) Output location change request

Symptom: The output was initially under docs/ but needed to live under static/.

Resolution: Updated all relevant fields from docs/infographic.html to static/infographic/index.html:

• metadata.outputs
• generation instructions
• artifact allow-list
• PR guidance

7) Merge model expectation mismatch

Symptom: Need was to merge automatically, ideally direct to main.

Root cause: gh-aw strict mode blocks write permissions such as contents: write, and safe output model is designed around controlled PR creation.

Resolution:

• Keep PR creation non-draft.
• Request auto-merge where possible.
• Accept that direct write to main is not supported in strict mode agentic workflow.

Final working configuration highlights

The stable setup now includes:

• create-pull-request with draft: false
• upload-artifact with staged: false
• upload-artifact.defaults.if-no-files: ignore
• allow-listed artifact path static/infographic/index.html
• threat-detection prompt tuned for static HTML/CSS output
• expanded data source instructions and GitHub API stats requirements

Practical lessons learned

1. Treat path handling as first-class design: generation path, artifact path, and allow-list must align exactly.
2. Distinguish transient platform faults from configuration faults before changing code.
3. In gh-aw strict mode, design around safe outputs and PR flows, not direct repository writes.
4. If output must always be visible, configure artifact handling to fail safely and avoid brittle staging assumptions.
5. Keep compile and lock-file generation in the tight edit loop.

Suggested validation checklist

Before each run:

• Confirm output target path is static/infographic/index.html everywhere.
• Confirm allowed-repos includes every cross-repo source.
• Confirm lock file is freshly compiled.
• Confirm safe output upload path is allow-listed.
• Confirm PR mode is non-draft if downstream automation expects merge.

Workflow sequence diagram

The sequence below shows how the agent run, safe outputs, artifact processing, and PR creation interact, including the path checks that caused previous failures.

sequenceDiagram
  autonumber
  participant U as User
  participant GW as gh-aw Workflow
  participant AG as Agent Job
  participant SO as Safe Outputs Handler
  participant FS as Workspace Files
  participant GH as GitHub API

  U->>GW: Trigger workflow_dispatch
  GW->>AG: Start agent run with prompt + constraints

  AG->>GH: Read README + cross-repo data + GitHub stats
  AG->>FS: Write static/infographic/index.html

  AG->>SO: Emit upload_artifact(path)
  SO->>FS: Validate path exists

  alt Path exists and allowed
    SO->>GW: Register upload_artifact success
    GW->>GH: Publish run artifact
  else Path missing or disallowed
    SO->>GW: upload_artifact validation failure
    Note over SO,GW: with defaults.if-no-files=ignore, run continues
  end

  AG->>SO: Emit create_pull_request(patch)
  SO->>GH: Apply patch to branch
  SO->>GH: Open PR (draft=false)

  alt Merge policy allows auto-merge
    GH-->>GW: Auto-merge enabled or completed
  else Branch protection blocks merge
    GH-->>GW: PR remains open for policy checks
  end

References

• GitHub Actions documentation
• GitHub REST API documentation
• Microsoft Learn profile transcript

Recap

This workflow succeeded once each failure mode was isolated and treated as a separate class of problem: compile hygiene, safe output validation, runtime transients, path contracts, and platform security constraints.

The result is a more reliable agentic pipeline that generates a static infographic from live data sources with controlled repository writes through a PR-first model.
